APS Technology Australia APS iRCBO

APS Technology Australia - APS iRCBO

Supplier: APS Technology Australia Pty Ltd

APS iRCBO

The APS iRCBO™ is an intelligent RCBO that combines earth-leakage, overload, and short-circuit protection with real-time metering, monitoring, and IoT connectivity—delivering advanced electrical safety for smart buildings and industry.

Specifications of this Product

Category	Specification
Functions	Earth leakage, overload, short circuit, over/under voltage, temperature alarm, arc-fault warning
Poles	1P+N, 2P, 3P, 4P
Rated Current	6A to 80A
Residual Current (IΔn)	30 mA (standard), optional 100 mA
Tripping Curves	B (3–5×In), C (5–10×In), D (10–14×In)
Breaking Capacity	6 kA (IEC 60898-1)
Metering	Voltage, Current, Power, Energy, Temperature, Power Factor
Communication	Wi-Fi, LAN, RS485, NB-IoT, GSM/GPRS, Zigbee, LoRa (via module)
Power Supply	90–250 VAC operating
Platform Integration	MTS3 Smart Electrical Safety System
Mechanical Life	20,000 operations
Electrical Life	10,000 operations
Mounting	35 mm DIN rail
Compliance	IEC 60898-1, CE

Features of this Product

Combines MCB, RCCB, smart meter, and IoT device in one unit
Life-saving 30 mA residual current protection
Overload and short-circuit protection with B/C/D trip curves
Arc-fault warning and high-temperature protection
Real-time electrical parameter monitoring
Remote ON/OFF control and automation
Fault logging, alarms, and historical data analysis
Supports clustered management of multiple breakers
Easy DIN-rail installation with modular communication

Applications of this Product

Residential

Home distribution boards
Wet areas and kitchens
Air conditioners and EV chargers
Smart home electrical protection

Commercial

Offices and retail buildings
Hotels and hospitality facilities
Schools and hospitals
Shopping centres and public infrastructure

Industrial

Control panels and distribution boards
Motor circuits requiring RCBO protection
Cold storage and production facilities
Solar inverter AC outputs

Smart Energy Management

Sub-circuit energy monitoring
Load profiling and analytics
Fault history tracking
Multi-site benchmarking

Why Choose This Product

Complete electrical protection in a single intelligent device
Enhances safety against electric shock, fire, and equipment damage
Enables remote monitoring, control, and diagnostics
Reduces panel space and wiring complexity
Supports smart building and Industry 4.0 initiatives
Powered by APS Technology’s MTS3 intelligent electrical safety platform

Specifications of this Product

Category	Specification
Functions	Earth leakage, overload, short circuit, over/under voltage, temperature alarm, arc-fault warning
Poles	1P+N, 2P, 3P, 4P
Rated Current	6A to 80A
Residual Current (IΔn)	30 mA (standard), optional 100 mA
Tripping Curves	B (3–5×In), C (5–10×In), D (10–14×In)
Breaking Capacity	6 kA (IEC 60898-1)
Metering	Voltage, Current, Power, Energy, Temperature, Power Factor
Communication	Wi-Fi, LAN, RS485, NB-IoT, GSM/GPRS, Zigbee, LoRa (via module)
Power Supply	90–250 VAC operating
Platform Integration	MTS3 Smart Electrical Safety System
Mechanical Life	20,000 operations
Electrical Life	10,000 operations
Mounting	35 mm DIN rail
Compliance	IEC 60898-1, CE

Features of this Product

Combines MCB, RCCB, smart meter, and IoT device in one unit
Life-saving 30 mA residual current protection
Overload and short-circuit protection with B/C/D trip curves
Arc-fault warning and high-temperature protection
Real-time electrical parameter monitoring
Remote ON/OFF control and automation
Fault logging, alarms, and historical data analysis
Supports clustered management of multiple breakers
Easy DIN-rail installation with modular communication

Applications of this Product

Residential

Home distribution boards
Wet areas and kitchens
Air conditioners and EV chargers
Smart home electrical protection

Commercial

Offices and retail buildings
Hotels and hospitality facilities
Schools and hospitals
Shopping centres and public infrastructure

Industrial

Control panels and distribution boards
Motor circuits requiring RCBO protection
Cold storage and production facilities
Solar inverter AC outputs

Smart Energy Management

Sub-circuit energy monitoring
Load profiling and analytics
Fault history tracking
Multi-site benchmarking

Why Choose This Product

Complete electrical protection in a single intelligent device
Enhances safety against electric shock, fire, and equipment damage
Enables remote monitoring, control, and diagnostics
Reduces panel space and wiring complexity
Supports smart building and Industry 4.0 initiatives
Powered by APS Technology’s MTS3 intelligent electrical safety platform
