Hydraulic NC Guillotine - HG-460B

Supplier: Hare & Forbes Machinery House

1300 x 6mm Mild Steel Shearing Capacity | 1-Axis Ezy-Set NC-89 Controlled Backgauge & Includes Rapid Blade Adjustment

Receive 1-3 days from order

Features

1300mm x 6mm cutting capacity
5.5kW / 7.5hp 415V motor
Ezy-Set NC-89 Go-To digital display controlled backgauge with DRO counter
Quick action blade clearance adjustment for shearing material 1 - 6mm
Hydraulic material clamping for accurate shearing
One shot lubrication pump & reservoir for slideway protection
Blades made from 9CrSi material suitable for cutting stainless steel
Transfer balls inserted into work table allowing larger sheets to be easily positioned to the cut position and squaring arm
Front sheet supports with ball bearing guides preventing material damage when setting up
Three safety photo electric light beams on rear guarding
Safety reset rear guarding button mounted to back of electrical box
Heavy duty under driven machine construction
Equipped with shadow line lighting-alignment device
Roving foot pedal control
Mild steel capacity is rated on hot rolled material with 250MPA
Pre-Commissioning:
1. Guillotine is run & tested prior delivery
2. Hydraulic oil is included with machine

To contact Hare & Forbes Machinery House about Hydraulic NC Guillotine - HG-460B use Get a quote.

Features

1300mm x 6mm cutting capacity
5.5kW / 7.5hp 415V motor
Ezy-Set NC-89 Go-To digital display controlled backgauge with DRO counter
Quick action blade clearance adjustment for shearing material 1 - 6mm
Hydraulic material clamping for accurate shearing
One shot lubrication pump & reservoir for slideway protection
Blades made from 9CrSi material suitable for cutting stainless steel
Transfer balls inserted into work table allowing larger sheets to be easily positioned to the cut position and squaring arm
Front sheet supports with ball bearing guides preventing material damage when setting up
Three safety photo electric light beams on rear guarding
Safety reset rear guarding button mounted to back of electrical box
Heavy duty under driven machine construction
Equipped with shadow line lighting-alignment device
Roving foot pedal control
Mild steel capacity is rated on hot rolled material with 250MPA
Pre-Commissioning:
1. Guillotine is run & tested prior delivery
2. Hydraulic oil is included with machine
