High Pressure Rotary Screw Compressor for ...

High Pressure Rotary Screw Compressor for Fiber Laser Cutting - EPM 22

Supplier: Hare & Forbes Machinery House

Direct Drive, Variable Speed, Permanent Magnet 22kW motor | 15.5 BAR - 2.1 m3/min

Receive 1-3 days from order

Overview

Born for laser cutting applications!

EPM-22 VARIABLE SPEED HIGH PRESSURE COMPRESSOR is designed for 6kW or higher Laser cutting with 15.5 BAR - 2.1 m3/min of compressed air.

In the process of laser cutting, the compressed air plays a key role in promoting combustion and heat dissipation while blowing the molten liquid away from the material and protecting the lens.

The EPM Series of Laser air compressors are designed to supply the higher pressures required to operate laser cutting machines as a suitable alternative to using Oxygen and Nitrogen bottle packs.

Features

All-in-one air solution with a Compact design for easy installation specifically for laser cutting applications
Latest Variable Speed Drive technology allows for the compressor to start and stop under full system pressure while reducing energy usage and increasing efficiency.
22Kw Oil Cooled Permanent Magnet Motor, generating less heat and friction compared to Induction motors resulting in higher efficiency and increased power density enabling a greater power output.
Refrigerated Air Dryer, Pre Filter and Post Filter fitted as standard for clean oil-less air supply
500L Tank
Australian Standard Certified for high pressure vessels

Includes

Pre Filter
Post Filter
Refrigerated Air Dryer
Variable Speed Drive Touch Screen Controller

Overview

Features

All-in-one air solution with a Compact design for easy installation specifically for laser cutting applications
Latest Variable Speed Drive technology allows for the compressor to start and stop under full system pressure while reducing energy usage and increasing efficiency.
22Kw Oil Cooled Permanent Magnet Motor, generating less heat and friction compared to Induction motors resulting in higher efficiency and increased power density enabling a greater power output.
Refrigerated Air Dryer, Pre Filter and Post Filter fitted as standard for clean oil-less air supply
500L Tank
Australian Standard Certified for high pressure vessels

Includes

Pre Filter
Post Filter
Refrigerated Air Dryer
Variable Speed Drive Touch Screen Controller

Read less...
