The 30 m³/h batching plant from Putzmeister is the perfect choice for start-up RMCs and construction projects or job sites where there are space constraints. Putzmeister uses the best of German engineering to design and manufacture batching plants that meet the requirements of the global construction industry in this category.

Key Features

• Configurable to meet every job site requirement
• Choice of different aggregate storage types and capacity
• Compact design for a smaller footprint on-site
• No concrete foundation is required for the skid (optional)
• Easy mobility between job sites
• Consistent, homogenous mixture with every batch
• Automation ensures a higher degree of accuracy in operations
• Easy drive-through, Transit Mixers don’t have to drive in reverse
• Preventive maintenance and interlocks in the control system
• Maintenance platforms with easy access to mixer, weighing systems and all other equipment

Technical Details

General Information

• Operating Voltage - Frequency: 415/50 V/Hz
• Automatic Batch Control: PC / Software

Configuration

MT 0.5 Inclined Belt Conveyor & Compartment Bins

• Plant Capacity: 30
• Space Required (L x W): 13 x 5 m
• Plant Height (without Silo): 8.4 m
• Concrete Discharge Height: 4.1 m
• Mixer Type: Twin Shaft TS 0.5
• Input Power: 18.5 kW
• Dry Filling: 0.75 m³
• Compacted Concrete: 0.5 m³
• Weighing System - Cement: 300 kg
• Weighing System - Water: 150 kg
• Weighing System - Additive: 6 kg
• Compressor : 9 bar
• Pressured Air Tank: 160 l
• Aggregate Storage - No. of Compartments (Std): 4
• Capacity of each Compartment: 6 m³
• Total Capacity (Std): 24 m³
• Batching Gate per Compartment : 1
• Filling Width per Compartment: 2.7 m
• Filling Height: 5.1 mm
• Automatic Batch Control: PC / Software
