High-capacity, mobile screening for organics and waste with up to 150 tonnes/hr throughput.

The TS516 is a compact mobile trommel screen designed for exceptional productivity and reliability in various screening applications, including organics, topsoil, bark, compost, woodchip, C&D waste, aggregates, and mining. Its robust build and mobility make it an efficient material separation solution without the need for complex fixed infrastructure.

Key Features

Tracked mobile trommel screening unit
Large capacity feed hopper
900 mm variable speed feeder conveyor
5.15 m screening drum with interchangeable screening media
Drum cleaning brush for consistent screening performance
900 mm collection conveyor
650 mm transfer conveyor
800 mm fines conveyor with high discharge height
Oversize discharge conveyor for separated materials
Variable speed control for feeder and conveyors
Heavy duty tracked chassis for on-site mobility
Diesel powerpack with high efficiency engine
Large access doors for service and maintenance
Robust steel construction for demanding applications
Capacity up to 150 tonnes per hour
Handles feed sizes up to 300 mm
Maximum screen size up to 60 mm

Options

Alternative screening drum sizes and mesh configurations
Extended fines conveyor
Additional stockpiling conveyors
Remote control operation
Dust suppression systems

Applications

FOGO processing
C&D waste screening
Aggregate screening
Mining applications
Topsoil and compost screening
Wood waste processing

Specifications

Weight	14,500 kg
Drum Length	5,150 mm
Drum Diameter	1,370 mm
Drum Angle Control	0–4°
Capacity	Up to 150 tonnes/hr
Maximum feed size	300 mm
Maximum screen size	60 mm
